| Presentation | Reliable rack power distribution designed to increase manageability and efficiency in the data center The output and input connections are (12)C13 Real-time remote monitoring of connected loads User-defined alarms warn IT and data center managers of potential circuit overloads to prevent accidental power loss to critical equipment. |
|---|---|
| Lead time | Usually in Stock |
| Colour | Black |
|---|---|
| Product or component type | PDU |
| PDU type | Basic |
| Cord length | 2.49 m |
| Number of cables | 1 |
| Provided equipment | Installation guide Rack mounting brackets |
| Input Voltage | 200 V 208 V 230 V |
|---|---|
| Height | 44 mm |
| Width | 447 mm |
| Output Voltage | 208 V 230 V |
| Depth | 57 mm |
| Net weight | 2.05 kg |
| Mounting location | Front Rear |
| Mounting preference | No preference |
| Input Plug Type | IEC 60320 C20 |
| Mounting mode | Rack-mounted |
| Rack units | 1U |
| Mounting position | Horizontal |
| Input current limits | 16 A |
| Load capacity | 3680 VA |
| Network frequency | 50/60 Hz |
| Outlet type and quantity | 12 IEC 60320 C13 |
| Product certifications | cUL listed CE Queensland Australia UL listed VDE |
|---|---|
| Standards | UL 60950 |
| Ambient air temperature for operation | 0…45 °C |
| Relative humidity | 0…95 % |
| Operating altitude | 0…10000 ft |
| Ambient air temperature for storage | -25…65 °C |
| Storage Relative Humidity | 0…95 % |
| Storage altitude | 0…15240 m |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 7 cm |
| Package 1 Width | 46.4 cm |
| Package 1 Length | 22.9 cm |
| Package 1 Weight | 3.632 kg |
| Warranty | 2 years repair or replace |
|---|
